Lenovo ThinkCentre M90a Gen 5

Šifra:
11VF-CTO
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
Lenovo ThinkCentre M90a Gen 5
With its sleek design, the Lenovo ThinkCentre M90a Gen 5 all-in-one is a PC powerhouse. It runs on up to the Intel vPro® platform with 14th Gen Intel® Core™ processing muscle and boasts a stunning FHD display, with or without touchscreen. Plus, optional discrete graphics are ideal for video-editing or design work. Mounted on a choice of stands, including one that’s full function with adjustable tilt, lift, pivot, and swivel. And there’s even a docking space for your phone and keyboard to keep your workspace clutter-free.

Processor:

  • 14th Generation Intel® Core™ i3-14100 Processor (P-Core Max 4.70 GHz with Turbo Boost, 4 Cores, 8 Threads, 12 MB Cache)

  • 14th Generation Intel® Core™ i5-14500 Processor with vPro® (E-Core Max 3.70 GHz, P-Core Max 5.00 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)

  • 14th Generation Intel® Core™ i7-14700 Processor with vPro® (E-Core Max 4.20 GHz, P-Core Max 5.30 GHz with Turbo Boost, 20 Cores, 28 Threads, 33 MB Cache)

Memory:

  • DDR5-4800
  • DDR5-5200
  • DDR5-5600

Two DDR5 SO-DIMM slots, dual-channel capable

Storage:

  • Models with Intel® UHD graphics:

Up to two drives, 2x M.2 SSD

  • M.2 SSD up to 2TB each
  • Models with NVIDIA® GeForce MX570A:

Up to one drives, 1x M.2 SSD

  • M.2 SSD up to 2TB each

RAID:

  • RAID 0/1 support for HDDs
  • No support

Removable Storage:

Optical:

  • DVD-ROM, SATA connector, slim (9.0mm)
  • DVD burner (DVD±RW), SATA connector, slim (9.0mm)
  • None

Card Reader: 3-in-1 card reader (SD, SDHC, SDXC)

Graphics:

  • Integrated Intel UHD graphics 730
  • Integrated Intel UHD graphics 770
  • Discrete NVIDIA GeForce MX570, 2GB GDDR6

Chipset: Intel Q670 Chipset

Operating System:

  • Windows® 11 Pro 64
  • Windows 11 Home 64
  • Windows 11 DG Windows 10 Pro 64
  • No operating system

Display: 23.8" FHD (1920x1080) IPS Anti-glare, 250 nits

Input Device:

Keyboard: USB Keyboard, Black, Slovenian

Mouse: USB Mouse, Black

Toucscreen: Advanced In-cell Touch (AIT), supports 10-point touch (optional)

Multi-Media:

Audio Chip: High Definition (HD) Audio, Realtek® ALC233NL-VB2-CG codec

Speakers: Stereo speakers, 3W x2, Dolby® Atmos®
Microphone: Dual array microphone

Camera:

  • 5.0-megapixel, IR + RGB hybrid, with ThinkShutter (physical switch on/off) and Human Presence Detection (Radar Sensor), ±20° view angle adjustable, Windows® Hello support
  • 5.0-megapixel, IR + RGB hybrid, with ThinkShutter (physical switch on/off), ±20° view angle adjustable, Windows® Hello support
  • 5.0-megapixel, with ThinkShutter (physical switch on/off)

Network:

Onboard Ethernet: Gigabit Ethernet, Intel Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN

WLAN + Bluetooth: (optional)

  • Realtek® Wi-Fi® 6 RTL8852BE, 802.11ax Dual Band 2x2 Wi-Fi® + Bluetooth® 5.3, M.2 card[
  • Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.2, M.2 Card
  • Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.3, Intel® vPro® technology support, M.2 Card

Ports/Slots:

Rear Ports:

  • 3x USB 3.2 Gen 1
  • 1x USB-C 3.2 Gen 2 (support data transfer and 15W charging)
  • 1x HDMI (HDMI in 1.4 / HDMI out 2.1 TMDS combo port)
  • 1x DisplayPort 1.4
  • 1x Ethernet (RJ-45)

Right Ports:

  • 3x USB 3.2 Gen 2
  • 1x headphone / microphone combo jack (3.5mm)

Optional Right Ports:

  • 1x card reader

System Management:

  • Intel vPro Enterprise
  • Non-vPro

Security:

Security Chip: Discrete TPM 2.0, TCG certified

Physical Locks: Kensington® Security Slot, 3 x 7 mm

Chassis Intrusion Switch: Chassis intrusion switch

BIOS Security:

  • Administrator password
  • Power-on password
  • Hard disk password
  • Boot sequence control
  • Boot without keyboard and mouse
  • Self-healing BIOS
  • Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
  • Individual USB port disablement

Power Supply:

  • 180W Fixed 90% Efficiency
  • 230W Fixed 92% Efficiency

Monitor Support:

Supports up to 3 independent displays via native display and 2 external monitor; supports external monitors via DisplayPort™ and HDMI; work as standalone monitor via HDMI (HDMI in / out combo)

Mechanical:

Buttons:

  • Power button
  • Microphone mute button
  • Monitor / PC mode switch button

Form Factor: AIO (23.8")

Dimensions (WxDxH):

  • Lowest in vertical mode (UltraFlex V Stand): 539.6 x 216.32 x 387.63 mm (21.24 x 8.52 x 15.26 inches)
  • Highest in vertical mode (UltraFlex V Stand): 539.6 x 216.32 x 472 mm (21.24 x 8.52 x 18.58 inches)

Weight: Around 8.13 kg

Case Color: Black
Bays:

  • 2x 2.5" disk bay (2nd 2.5" HDD occupies ODD bay)
  • 1x slim ODD bay

Expansion slots: Two M.2 slots (one for WLAN, one for SSD)
Stand: UltraFlex V stand, supports -5° to +70° tilt, up to 70°±2° lift (up to 174.02mm lift in flat mode / up to 84.37mm lift in vertical mode)

Mounting: VESA 100x100 Support

What's in the Box:

  • ThinkCentre M90a Pro Gen 5 (23.8" Intel)
  • UltraFlex V Stand
  • AC Adapter
  • USB Keyboard
  • USB Mouse
  • Quick Start Guide
