Lenovo ThinkPad T14 Gen 5 (AMD)

Processors:

• AMD Ryzen™ 5 PRO 8540U Processor (3.20 GHz up to 4.90 GHz Max Boost, 6 Cores, 12 Threads, 16 MB Cache)
• AMD Ryzen™ 7 PRO 8840U Processor (3.30 GHz up to 5.10 GHz Max Boost, 8 Cores, 16 Threads, 16 MB Cache)

Display:

• 14" WUXGA (1920x1200), IPS, 400 nits, Anti-glare, 16:10, 1000:1, 45% NTSC, 60Hz, 3M™ DBEF5
• 14" WUXGA (1920x1200), Multi-touch, IPS, 400 nits, Anti-glare, 16:10, 1000:1, 45% NTSC, 60Hz, 3M™ DBEF5
• 14" WUXGA (1920x1200), IPS, 400 nits, Anti-glare, 16:10, 1000:1, 100% sRGB, 60Hz, Low power, Eyesafe® Certified 2.0,
• 14" WUXGA (1920x1200), Multi-touch, IPS, 500 nits, Anti-glare, 16:10, 1500:1, 100% sRGB, 60Hz, ThinkPad® Privacy Guard,
• 14" 2.8K (2880x1800), OLED, 400 nits, Anti-glare, anti-reflection, anti-smudge, 16:10, 100,000:1, 100% DCI-P3, 120Hz, DisplayHDR™ True Black 500, Dolby Vision®, Eyesafe® Certified 2.0,

Memory:

• Max memory:  Up to 64GB DDR5-5600
• Memory slots:  Two DDR5 SO-DIMM slots, dual-channel capable

Storage:  One drive, up to 2TB M.2 2280 SSD; One M.2 2280 PCIe® 4.0 x4 slot

Graphics:

• AMD Radeon™ 740M
• AMD Radeon™ 780M

Operating system:

• Windows® 11 Pro
• Windows® 11 Home

Input device:

Keyboard: 6-row, spill-resistant, multimedia Fn keys, Copilot key

Keyboard Backlight: LED backlight (Optional)

UltraNav:

• TrackPoint® pointing device, double-tap to open the TrackPoint® Quick Menu
• Glass-like Mylar® surface multi-touch touchpad, 61 x 115 mm (2.40 x 4.53 inches)

Multi-media:

Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers: Stereo speakers, 2W x2, Dolby Audio™

Microphone: Dual-microphone array, 360° far-field, Dolby Voice®

Camera:

• 5.0MP + IR discrete, with privacy shutter, fixed focus, temporal noise reduction
• 5.0MP, with privacy shutter, fixed focus, temporal noise reduction

Network:

Ethernet: Gigabit Ethernet, Realtek® RTL8111EPV, 1x RJ-45, supports Wake-on-LAN

WLAN + Bluetooth:

• Qualcomm® Wi-Fi® 6E NFA725A, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.3
• Qualcomm® Wi-Fi® 7 NCM825, 802.11be 2x2 Wi-Fi® + Bluetooth® 5.3 (Bluetooth® 5.4 hardware ready

WWAN: (optional)

• Wireless WAN upgradable to 4G (with antenna ready)
• Wireless WAN upgradable to 4G or 5G (with antenna ready)
• Quectel EM061K-GL, 4G LTE CAT6, M.2 Card, with embedded eSIM functionality
• Quectel EM160R-GL, 4G LTE CAT16, M.2 card, with embedded eSIM functionality
• Quectel RM520N-GL, 5G Sub-6 GHz, M.2 Card, with embedded eSIM functionality

Ports/slots:

Standard Ports:

• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
• 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
• 1x HDMI® 2.1, up to 4K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Ethernet (RJ-45)

Optional Ports:

• 1x Smart card reader
• 1x Nano-SIM card slot (WWAN support models)

System Management: DASH

Security:

Security Chip: Discrete TPM 2.0, (TCG certified, FIPS 140-2 certified) and Microsoft® Pluton TPM 2.0, one enabled at one time

Physical Locks: Kensington® Nano Security Slot, 2.5 x 6 mm

Fingerprint Reader:  Touch style fingerprint reader integrated in power button, match-on-chip

BIOS Security:

• NVMe® password
• Power-on password
• Supervisor password
• System management password
• Certificate based BIOS authentication
• FIDO (Fast Identity Online) authentication
• Self-healing BIOS

Other Security:

• Camera privacy shutter (camera models)
• Privacy Guard with Privacy Alert (models with ThinkPad® Privacy Guard display)
• (Optional) IR camera for Windows® Hello (facial recognition)
• (Optional) Ultrasonic Human Presence Detection

Battery:

• Integrated Li-Polymer 39.3Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 65W AC adapter
• Integrated Li-Polymer 52.5Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 65W AC adapter

Monitor Support:

Supports up to 4 independent displays (native display and 3 external monitors via HDMI® and Thunderbolt™)

• HDMI® supports up to 4K@60Hz
• Thunderbolt™ supports up to 5K@60Hz

Mechanical:

Dimensions (WxDxH): 315.9 x 223.7 x 17.7 mm

Weight:  Starting at 1.31 kg up to 1.38 kg

Case Color:  Black

Case Material:  PC + 20% CF

What's in the Box:

• ThinkPad T14 Gen 5 (14” AMD)
• 52.5 Internal Battery
• 65W AC Adapter
• Quick Start Guide
