Lenovo ThinkPad Z16 Gen 1

Processor: AMD Ryzen™ 5 / 7 / 9 Processor

Display:

• 16" WUXGA (1920 x 1200) IPS, anti-glare, 400 nits
• 16" WQUXGA (3840x2400) IPS, anti-reflection, anti-smudge, touchscreen, 400 nits
• 16" WUXGA (1920x1200) IPS, touchscreen, anti-glare, anti-smudge, 400 nits

Memory:

Max Memory

• 16GB soldered memory, not upgradable
• 32GB soldered memory, not upgradable

Memory Slots

Memory soldered to systemboard, no slots, dual-channel

Memory Type

LPDDR5-6400

Storage:

Storage Support

One drive, up to 2TB M.2 2280 SSD

Storage Slot

One M.2 2280 PCIe® Gen 4x4 slot, supports M.2 2242/2280 SSD

Graphics:

• Integrated AMD Radeon 660M
• Integrated AMD Radeon 680M
• Discrete AMD Radeon 6500M 4GB GDDR6

Operating System:

• Windows® 11 Pro 64
• Windows 11 Home 64
• Windows 11 DG Windows 10 Pro 64
• Fedora Linux
• Linux
• Ubuntu Linux
• No operating system

Input Device:

Pen

No pen (pen sold separately)

Keyboard

6-row, spill-resistant, multimedia Fn keys with Unified Communications controls

Keyboard Backlight

LED backlight

UltraNav™

TrackPoint® pointing device and glass surface multi-touch Haptic ForcePad, 67 x 120 mm (2.64 x 4.72 inches)

Multi-Media:

Audio Chip

High Definition (HD) Audio, Realtek® ALC3306 codec

Speakers

Stereo speakers, 2W x2, Dolby® Atmos®

Microphone

Dual array microphone, 360° far-field, Dolby Voice

Camera

• IR & FHD 1080p hybrid, with E-camera shutter, fixed focus
• IR & FHD 1080p discrete, with E-camera shutter, fixed focus

Network:

WLAN + Bluetooth

Qualcomm® NFA-725A Wi-Fi® 6E, 802.11ax 2x2 Wi-Fi + Bluetooth 5.2

WWAN

• Fibocom L860-GL-16, 4G LTE CAT16, M.2 card
• Quectel EM05-G, 4G LTE CAT4, M.2 card
• No support

SIM Card

• Gemalto eSIM
• No SIM card inbox

Ports/Slots:

Standard Ports

• 1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a)
• 2x USB4 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4a)
• 1x SD card reader
• 1x Headphone / microphone combo jack (3.5mm)

Optional Ports

1x Nano-SIM card slot (WWAN support models)

System Management:

• DASH
• Non-DASH

Security:

Security Chip

• Discrete TPM 2.0, TCG certified, with Microsoft Pluton TPM 2.0 integrated in SoC
• Microsoft Pluton TPM 2.0 integrated in SoC

Physical Locks

Kensington® Nano Security Slot, 2.5 x 6 mm

Fingerprint Reader

Touch style fingerprint reader in keyboard key, match-on-chip

BIOS Security

• Power-on password
• Supervisor password
• System management password
• NVMe password
• USB FIDO (Fast Identity Online) device integration
• Certificate based BIOS authentication
• Self-healing BIOS

Other Security

• E-Camera shutter
• IR camera for Windows Hello
• Mirametrix Glance

Battery:

• Integrated Li-Polymer 52.5Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 65W or 135W AC adapter
• Integrated Li-Polymer 86Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 135W AC adapter

Monitor Support:

Supports up to 4 independent displays (native display and 3 external monitors via USB4® or USB-C®)

• USB4 supports up to 8K@30Hz
• USB-C supports up to 4K@60Hz (4 displays output), 5K@60Hz (3 displays output) or 5K@120Hz (up to 2 displays output)

Mechanical:

Dimensions (WxDxH)

354.4 x 237.4 x 15.8 mm (13.95 x 9.35 x 0.62 inches)

Weight

Starting at 1.94 kg (4.27 lbs)

Case Color

Arctic grey (top), black (bottom)

Case Material

Aluminium (top), aluminium (bottom)

Full spec list for ThinkPad Z16 Gen 1 model starting with 21D4 available here
