Processor:
- 13th Generation Intel® Core™ i3-13100 Processor (P-Core Max 4.50 GHz with Turbo Boost, 4 Cores, 8 Threads, 12 MB Cache)
- 13th Generation Intel® Core™ i5-13400 Processor (E-Core Max 3.30 GHz, P-Core Max 4.60 GHz with Turbo Boost, 10 Cores, 16 Threads, 20 MB Cache)
- 13th Generation Intel® Core™ i5-13500 Processor with vPro® (E-Core Max 3.50 GHz, P-Core Max 4.80 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 13th Generation Intel® Core™ i5-13600 Processor with vPro® (E-Core Max 3.70 GHz, P-Core Max 5.00 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 13th Generation Intel® Core™ i5-13600K Processor with vPro® (E-Core Max 3.90 GHz, P-Core Max 5.10 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 13th Generation Intel® Core™ i7-13700 Processor with vPro® (E-Core Max 4.10 GHz, P-Core Max 5.10 GHz with Turbo Boost, 16 Cores, 24 Threads, 30 MB Cache)
- 13th Generation Intel® Core™ i7-13700K Processor with vPro® (E-Core Max 4.20 GHz, P-Core Max 5.30 GHz with Turbo Boost, 16 Cores, 24 Threads, 30 MB Cache)
- 13th Generation Intel® Core™ i9-13900 Processor with vPro® (E-Core Max 4.20 GHz, P-Core Max 5.20 GHz with Turbo Boost, 24 Cores, 32 Threads, 36 MB Cache)
- 13th Generation Intel® Core™ i9-13900K Processor with vPro® (E-Core Max 4.30 GHz, P-Core Max 5.40 GHz with Turbo Boost, 24 Cores, 32 Threads, 36 MB Cache)
- 14th Generation Intel® Core™ i3-14100 Processor (P-Core Max 4.70 GHz with Turbo Boost, 4 Cores, 8 Threads, 12 MB Cache)
- 14th Generation Intel® Core™ i5-14400 Processor (E-Core Max 3.50 GHz, P-Core Max 4.70 GHz with Turbo Boost, 10 Cores, 16 Threads, 20 MB Cache)
- 14th Generation Intel® Core™ i5-14500 Processor with vPro® (E-Core Max 3.70 GHz, P-Core Max 5.00 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 14th Generation Intel® Core™ i5-14600 Processor with vPro® (E-Core Max 3.90 GHz, P-Core Max 5.20 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 14th Generation Intel® Core™ i5-14600K Processor with vPro® (E-Core Max 4.00 GHz, P-Core Max 5.30 GHz with Turbo Boost, 14 Cores, 20 Threads, 24 MB Cache)
- 14th Generation Intel® Core™ i7-14700 Processor with vPro® (E-Core Max 4.20 GHz, P-Core Max 5.30 GHz with Turbo Boost, 20 Cores, 28 Threads, 33 MB Cache)
- 14th Generation Intel® Core™ i7-14700K Processor with vPro® (E-Core Max 4.30 GHz, P-Core Max 5.50 GHz with Turbo Boost, 20 Cores, 28 Threads, 33 MB Cache)
- 14th Generation Intel® Core™ i9-14900 Processor with vPro® (E-Core Max 4.30 GHz, P-Core Max 5.40 GHz with Turbo Boost, 24 Cores, 32 Threads, 36 MB Cache)
- 14th Generation Intel® Core™ i9-14900K Processor with vPro® (E-Core Max 4.40 GHz, P-Core Max 5.60 GHz with Turbo Boost, 24 Cores, 32 Threads, 36 MB Cache)
Memory:
Max Memory: Up to 128GB (4x 32GB DDR5 UDIMM)
Memory Slots: Four DDR5 DIMM slots, dual-channel capable
Memory Type:
- DDR5-4400 UDIMM ECC, maximum transfer speeds of up to 4400 MT/s
- DDR5-4400 UDIMM non-ECC, maximum transfer speeds of up to 4400 MT/s
Storage:
Up to five drives (4x HDD + 1x M.2 SSD) or six drives (3x HDD + 3x M.2 SSD)
- 3.5" HDD up to 6TB each
- 2.5" HDD up to 1TB each
- M.2 SSD up to 4TB or 2TB each (2280)
Graphics:
Integrated:
- Intel® UHD Graphics 730
- Intel® UHD Graphics 770
Discrete:
Supports up to one NVIDIA® RTX 5000 Ada Generation or two NVIDIA® RTX A2000
- NVIDIA® RTX A1000 4GB GDDR6
- NVIDIA® RTX A400 8GB GDDR6
- NVIDIA® T400 4GB GDDR6
- NVIDIA® T1000 8GB GDDR6
- NVIDIA® RTX A2000 12GB GDDR6
- NVIDIA® RTX A4000 16GB GDDR6 with ECC
- NVIDIA® RTX A4500 20GB GDDR6 with ECC
- NVIDIA® RTX A5000 24GB GDDR6 with ECC
- NVIDIA® RTX A5500 24GB GDDR6 with ECC
- NVIDIA® RTX 2000 Ada Generation 16GB GDDR6
- NVIDIA® RTX 4000 Ada Generation 20GB GDDR6 with ECC
- NVIDIA® RTX 4500 Ada Generation 24GB GDDR6 with ECC
- NVIDIA® RTX 5000 Ada Generation 32GB GDDR6 with ECC
Chipset: Intel W680 Chipset
Operating System:
- Windows® 11 Pro
- Windows® 11 Home
- Windows® 11 DG Windows® 10 Pro 64
- Ubuntu Linux LTS
- Red Hat Enterprise Linux 9.2
- No preload operating system
Multi-Media:
Audio Chip: High Definition (HD) Audio, Realtek® ALC897Q-CG codec
Speakers: Single speaker, 2W x1
Network:
Onboard Ethernet: Gigabit Ethernet, Intel Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN
Optional Ethernet:
Up to two additional PCIe® x1 Ethernet adapters or one PCIe® x4 or x8 Ethernet adapter support; up to two additional 25GbE ports
- Gigabit Ethernet, Intel® I210-T1, 1x RJ-45, PCIe® x1
- Gigabit Ethernet, Intel® I350-T2, 2x RJ-45, PCIe® x4
- Gigabit Ethernet, Broadcom BCM5719, 4x RJ-45, PCIe® x4
- Gigabit Ethernet, Broadcom BCM5720, 2x RJ-45, PCIe® x1
- Gigabit Ethernet, Realtek® RTL8168H, 1x RJ-45, PCIe® x1
- 2.5 Gigabit Ethernet, Realtek® RTL8125BGS, 1x RJ-45, PCIe® x1
- 10 Gigabit Ethernet, Marvell AQtion AQN-107, 1x RJ-45, PCIe® x4
- 10 Gigabit Ethernet, Intel® X710-T2L, 2x RJ-45, PCIe® x8
- 25 Gigabit Ethernet, NVIDIA® Mellanox ConnectX-6, 2x SFP28, PCIe® x8
WLAN + Bluetooth:
- Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.1 (Bluetooth® 5.3 hardware ready), Intel® vPro® technology support[1]
- No WLAN and Bluetooth®
Ports/Slots:
Front Ports:
- 1x USB-C® (3.2 Gen 2), data transfer only
- 2x USB-A (USB 3.2 Gen 1)
- 2x USB-A (USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
Rear Ports:
- 4x USB-A (USB 3.2 Gen 1), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 2x DisplayPort™ 1.4
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
Optional Rear Ports:
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with DisplayPort™ function (Flex IO)
- 1x HDMI® 2.1 TMDS (Flex IO)
- 1x DP 1.2 (Flex IO)
- 1x VGA (Flex IO)
- 1x parallel (via cable and PCIe® bracket)
- 1x Thunderbolt™ 4 (via additional PCIe® adapter)
- 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), support data transfer, via USB-C® PCIe® x4 card
- 2x USB-A (Hi-Speed USB / USB 2.0), via cable and PCIe® bracket
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), via additional PCIe® adapter
- 1x serial (via cable)
- 4x serial (via 4-port serial expansion card, PCIe® x1)
- 2x PS/2 (via cable)
System Management:
- Intel® vPro® Enterprise with Intel® AMT 16
- Non-vPro®
Security:
Security Chip: Discrete TPM 2.0, TCG certified
Physical Locks:
- Kensington® Security Slot, 3 x 7 mm
- (Optional) Cable lock
- (Optional) E-lock
- Padlock Loop
Chassis Intrusion Switch: Chassis intrusion switch (optional)
BIOS Security:
- Administrator password
- Power-on password
- Self-healing BIOS
- UEFI Secure Boot
Power Supply: 500W / 750W / 1100W / Fixed, 92% Efficiency, Autosensing, 80 PLUS Platinum qualified
Monitor Support: Supports multiple displays via onboard video ports and discrete graphics, the number of maximum monitors supported depends on the graphic card in use
Mechanical:
Form Factor: Tower (17L)
Dimensions (WxDxH): 180 x 370 x 415 mm
Weight: Around 13.61 kg
Case Color: Black
Bays:
Up to four disk bays:
- Bay 1 supports one 3.5" / 2.5" drive, standard
- Bay 2 supports one 3.5" / 2.5" drive, optional
- Bay 3 supports one 3.5" / 2.5" drive, optional
- Bay 4 supports one 3.5" / 2.5" drive, optional
- Front Access HDD Bay supports one 3.5" / 2.5" drive, optional, occupies Bay 3 location
Expansion slots:
Supports four PCIe® slots with two PCIe® 4.0 x16 and two PCIe® 3.0 x1.
- Slot 1: PCIe® 4.0 x16, full height, full length, 75W, double-width
- Slot 2: PCIe® 3.0 x1, full height, half length, 25W
- Slot 3: PCIe® 4.0 x16 (x4 lanes), full height, half length, 25W
- Slot 4: PCIe® 3.0 x1, full height, half length, 25W
What's in the Box:
- ThinkCentre P3 Tower (Intel)
- Power supply
- USB Traditional Keyboard, Black, Slovenian
- USB Calliope Mouse, Black
- Quick Start Guide
